Description:

The Trend KWJ/OSD Worktop True Cut Kitchen Worktop Jig Out of Square Device Worktop Jig Accessory is for making fast, accurate angled worktop joints to accommodate out of square walls.

Features:

Adaptable angle range - can be used for acute and obtuse wall angles up to 25 degrees out of square
Works with Trend KWJ 750P Pro, KWJ 900P Pro, KWJ 700, KWJ 700S, KWJ 900 worktop jigs and jigs up to 12mm thick
Easy setup and fast alignment to the worktop edge ensures correct backset position
Simple 4 step procedure - Measure, Mark, Clamp and Cut
Precision fit - front edge pivot point alignment ensures the backset is correctly set to match the female cut
Works with any worktop edge profile from square edge to full bullnose
Two-part construction with keyed interlock to swivel easily into place and clamp firmly onto the jig without slipping
High quality spring-loaded handle for fast adjustment and secure lock

Product Specification:

Barcode: 5027654071953
Part No.: KWJ/OSD
Out of Square Capacity: Up to 25 Degree
Max. Jig Thickness: 12mm
Height: 73mm
Width: 73mm
Depth: 17mm
Weight: 0.25kg
